Product Features
Easy assembly, no need for adjustments
Stable signal transmission with a recognition range of up to 50 meters
Precise current control with rapid response
Suitable for installation in various environments
Leakage Protection With Type A sensor + DC6mA sensor
Appearance customization
6 color appearances can be customized upon request
Description
Multiple Versions
Basic Version: A plug-and-play solution for easy and reliable charging. No apps, settings, or complex controls—just plug in and charge. Perfect for users who want a simple, no-frills home charging experience.
App Control Version: It is a smart EV charging station that, through our dedicated mobile APP, allows you to freely set charging time and duration, make reservations for charging, and view your charging history.
RFID Card Swipe Version: Ideal for shared charging locations, allowing only authorized users to access the charger.
Dynamic Load Balancing Version: Automatically adjusts power distribution in real-time, preventing electrical overload while ensuring fast and stable charging.
OCPP Version: Supports seamless integration with central management systems, remote diagnostics, and flexible payment solutions.
Single Phase or Three Phase Options
EVTAURUS Dynamic Load Balancing charging station is adaptable for both single-phase and three-phase home electrical systems, ensuring efficient charging for any setup. Our range includes J1772 chargers for North American customers and IEC 62196-2 (Type 2) connectors for those in Europe or other regions with three-phase charging
Smarter Charging
As homes use more and more electricity, managing power efficiently is becoming essential. The EVTAURUS Dynamic Load Balancing EV charging helps by automatically balancing the power between your devices, appliances, and systems. This prevents overloading and keeps everything running smoothly. The charger’s display screen or a user-friendly smartphone app allows for easy monitoring of the EV charging status, providing a convenient and smart approach to managing energy consumption
Business Value
High Efficiency Reduces Operating Costs
With >96% efficiency, >0.99 power factor and <8W standby power consumption, the ES-AC10 AC EV Charger minimizes long-term energy waste. For multi-unit commercial installations, this delivers measurable, ongoing electricity cost savings.
Long Service Life Lowers Total Cost of Ownership
Its 30,000-hour MTBF and premium component selection cut maintenance frequency and replacement costs. The 17kg metal housing offers extra durability for high-traffic public sites, while the 8.5kg lightweight PC-ABS version suits easy residential installation.
Flexible Configuration Reduces Inventory Complexity
With 5 functional versions, 2 housing materials, 6 color options, customizable cable lengths and multiple connector types, distributors can stock one EV charging station platform and configure it per project. This cuts SKU volume while covering diverse customer requirements.
OEM and Software Customization
EVTAURUS offers 6 housing color options for appearance customization. The OCPP-enabled version supports branded software integration with central management systems, enabling private-label networks, custom tariff structures and remote fleet/utility diagnostics.
Applications
- Residential home charging: Basic or APP Control versions deliver convenient overnight charging with 3.5kW/7kW single-phase output, sufficient for daily commutes. The Dynamic Load Balancing version is ideal for homes with solar panels, heat pumps or shared electrical capacity.
- Workplace & destination charging: Offices, hotels and retail sites can deploy RFID or OCPP versions as an employee/guest amenity, with access control and usage tracking. Its IP65 rating supports open parking lot installation without extra weather protection, with OCPP-enabled centralized billing.
- Shared apartment & condominium complexes: RFID Card Swipe versions restrict access to authorized residents. Dynamic Load Balancing prevents building electrical panel overload when multiple units run simultaneously, supporting multi-unit deployment in shared parking facilities.
- Commercial fleet depots: OCPP versions enable centralized monitoring and scheduled overnight charging. 22kW three-phase output cuts per-vehicle charge time, while the metal housing offers impact resistance for high-traffic depot environments.
Customization & Packaging Options
The ES-AC10 AC EV Charger offers full customization to match project and branding needs. Standard housing is white, with 6 additional custom color options available. Charging cables come in a standard 5m length, with custom lengths available for specific installation layouts. Two housing materials are offered: flame-retardant PC-ABS (8.5kg, residential use) and reinforced metal (17kg, high-traffic commercial use).
For OCPP models, firmware can be tailored to integrate with proprietary central management systems, supporting custom branding, tariffs and remote diagnostics. Connector options include Type 1 (J1772, North America), Type 2 (IEC 62196-2, Europe), Tesla-compatible and GB/T (China), covering all major global markets.
Quality & Safety
The ES-AC10 meets strict global safety and reliability standards. Its PC-ABS housing is UL94-V0 flame-retardant, with an IP65 rating for full dust protection and water jet resistance from all directions.
Built-in protection circuits include Type B RCD (detects both AC and DC fault currents), paired with Type A sensors and DC6mA leakage detection for enhanced safety. Overcurrent protection activates at 110% of rated load, with ±1% voltage and current regulation accuracy across all load ranges.
Additional reliability specs include >10MΩ insulation resistance, 1500V AC dielectric strength verification, and <5% current harmonic distortion at 50-100% load. With a 30,000-hour MTBF and forced-air cooling, this AC charging station operates reliably across a -30°C to +70°C temperature range.
Why Choose AC EV Charger from EVTAURUS
EVTAURUS engineered the ES-AC10 AC EV Charger to balance flexible configuration with robust industrial-grade performance. The unified hardware platform covers plug-and-play basic units, OCPP smart chargers and load-balancing models, serving residential, commercial and fleet scenarios with minimal adaptation. Buyers can select single/three-phase input, 5 control versions, 2 housing materials, 6 colors and 4 connector types, paying only for features their project requires.
Its IP65 enclosure, wide operating temperature range and full protection suite deliver reliable deployment in nearly any environment. >96% efficiency and intelligent dynamic load balancing reduce both energy costs and multi-unit overload risks. Backed by a 30,000-hour MTBF and premium components, this EV charging station is built for years of consistent daily operation.
FAQ
Q1: What power levels does the ES-AC10 AC EV Charger support?
A: It supports 3.5kW, 7kW, 11kW and 22kW output, available in single-phase or three-phase 16A/32A input configurations.
A: It supports 3.5kW, 7kW, 11kW and 22kW output, available in single-phase or three-phase 16A/32A input configurations.
Q2: Which connector types are available for this EV charging station?
A: It offers Type 1 (J1772), Type 2 (IEC 62196-2), Tesla-compatible and GB/T connectors, covering North American, European and Asian markets.
A: It offers Type 1 (J1772), Type 2 (IEC 62196-2), Tesla-compatible and GB/T connectors, covering North American, European and Asian markets.
Q3: Can the ES-AC10 be used outdoors?
A: Yes. It carries an IP65 protection rating, operates across -30°C to +70°C, and features moisture, mildew and salt spray resistance, making it fully suitable for outdoor installation.
A: Yes. It carries an IP65 protection rating, operates across -30°C to +70°C, and features moisture, mildew and salt spray resistance, making it fully suitable for outdoor installation.
Q4: What versions of the charger are available?
A: Five versions are available: Basic (plug-and-play), APP Control (smartphone scheduling/monitoring), RFID Card Swipe (access control), Dynamic Load Balancing (automatic power distribution), and OCPP (central management system integration).
A: Five versions are available: Basic (plug-and-play), APP Control (smartphone scheduling/monitoring), RFID Card Swipe (access control), Dynamic Load Balancing (automatic power distribution), and OCPP (central management system integration).
Q5: How does Dynamic Load Balancing work?
A: This smart EV charger syncs with building electrical systems and adjusts power draw in real time to prevent overloads, while maintaining the fastest possible charging speed for available capacity.
A: This smart EV charger syncs with building electrical systems and adjusts power draw in real time to prevent overloads, while maintaining the fastest possible charging speed for available capacity.
Q6: What protection features does this electric vehicle charger include?
A: It includes Type B RCD residual current protection, Type A + DC6mA leakage detection, 110% threshold overcurrent protection, >10MΩ insulation resistance and 1500V AC dielectric strength testing.
A: It includes Type B RCD residual current protection, Type A + DC6mA leakage detection, 110% threshold overcurrent protection, >10MΩ insulation resistance and 1500V AC dielectric strength testing.
Q7: What is the efficiency of this AC charging station?
A: It delivers >96% efficiency with >0.99 power factor at 50-100% load, with standby power consumption below 8W.
A: It delivers >96% efficiency with >0.99 power factor at 50-100% load, with standby power consumption below 8W.
Q8: Can the appearance of the charger be customized?
A: Yes. It offers 6 custom color options in addition to standard white, with customizable charging cable lengths beyond the standard 5m.
A: Yes. It offers 6 custom color options in addition to standard white, with customizable charging cable lengths beyond the standard 5m.
